Air-to-Water Heat Pump Water Heater Aquathermica Compact HPWH 3.2 100

Description

Air-to-Water Heat Pump Water Heater Aquathermica Compact HPWH 3.2 WH 100 U01

AquaThermica Compact is a wall-hung air-to-water heat pump water heater for domestic hot water production. Environmentally friendly product, operating with renewable energy sources resulting in lower CO2 emissions.

An environmentally friendly product, operating with renewable energy sources resulting in lower CO2 emissions.

- The highest energy efficiency class A+

- Operates within a wide temperature range of the incoming air starting from -5°C to 43°C.

- Heats up water to 60° C with the heat pump only

- Precise measuring the refrigerant cycle for better performance

- Ecological refrigerant R513

- Up to 75% lower electricity consumption

- Can be connected to a photovoltaic panel

- Automatic anti-legionella cycle

- Self-diagnostic system

Specifications

Capacity 98 L
Energy class A+
Maximum working pressure 8 bar
Diameter 520 mm
Heating time 7:04 h:min
Declared load profile M
Min. ÷ max temperature heat pump air intake (90% R.H.) -5 ÷ 43 °C
Frequency 50 Hz
Power supply 1/N/220-240 V
Compressor Rotary
Min. ÷ max temperature installation site 4 ÷ 40 °C
Compressor protection Thermal circuit breaker with automatic reset
Fan Centrifugal
HP Maximum settable temperature 60 [70] °C
Motor protection Internal thermal circuit breaker with automatic reset
Condenser Wrapped externally not in contact with water
Automatic anti-Legionnella disinfection cycle YES
CoP (DHW) 2.8
Heat Pump Thermal Power yield (P rated) Active hot gas defrost with kW
Refrigerant R513 a
Refrigerant charge 760 g
CO2 equivalent 0.480
Max. quantity of hot water at 40; V40; [EN16147:2017] 135 L
