❄️ Complete 3m Air Conditioning Installation Kit 9000-12000 BTU - Model EC118-1

Are you looking for a complete and reliable air conditioning installation kit for your 9000 or 12000 BTU unit? Choose the EC118-1 kit, the ideal solution that contains all the essential components for a quick, safe and professional installation of the split unit.

Don't skimp on quality! A correctly installed refrigerant line ensures optimal efficiency of the air conditioner and extends its lifespan.

Why choose the EC118-1 AC Installation Kit?

This complete AC 9000-12000 BTU installation kit is designed to fit perfectly with most standard air conditioner models in this power range.

Extended Compatibility: Ideal for 9000 BTU and 12000 BTU (9k BTU / 12k BTU) units.

Quality Components: Includes essential elements such as 1/4" insulated copper pipe and 3/8" insulated copper pipe, which ensure perfect tightness and minimal heat loss in the refrigerant circuit.

All in One Package: The kit contains, in addition to the copper pipes and outdoor unit support, electrical cables (for power and communication), condensate hose and all necessary fixing accessories (dowel, screws, mitre tape).

EC118-1 Kit Contents (Standard 3 Meters):
Check the detailed list of included materials to make sure you have everything you need for the installation:

Refrigerant Line:

Insulated Copper Pipe 1/4" (6.35 mm) - Length: 3 meters

Insulated Copper Pipe 3/8" (9.52 mm) - Length: 3 meters

Cables:

MYYM 3x1.5 mm² Electrical Cable - Power (4 m)

MYYM 5x1.5 mm² Electrical Cable - Communication (4 m)

Drainage:

Condensate Hose (Drain) - 3 m

Mounting Accessories:

Eurocool Folding Support 400x450x1.5 mm – 1 set
Matching Tape
Insulation Tape
Dowels and Hexagonal Head Screws 12 x 200 mm – 4 pieces
Metric Screws 8 x 30 mm (with washer and nut) – 4 pieces
Percussion Nail Dowel 6×40 mm – 4 pieces.

Purchase now the Air Conditioning Installation Kit 9000-12000 EC118-1 from Termix and benefit from professional products, essential for air conditioning your home.
