Horizontal Inox Pressure Tank Type 24
Description
Horizontal Inox Pressure Tank IBO Type 24
The 24 horizontal pressure tanks are made of AISI 304 stainless steel for storing water in water supply systems.
Tank jacket and flange are made of stainless steel. IBO pressure vessels are used to stabilize water pressure and increase the live volume of water supply systems.
Designed to operate with pumps with parameters matching the tank parameters.
Due to the stainless steel finish, the tanks can be installed in wells and wet rooms without the risk of early corrosion. There are EPDM rubber diaphragms inside the tanks creating a membrane between the water inside it and the
outer jacket of the tank. Compressed air between the membrane and the tank body releases water from the tank under pressure.
By using tanks in booster sets, the number of pump starts in a given period of time can be limited, which results in the extended lifespan of the entire system. The volume of water inside the tank is the difference between the tank body volume and the volume of air around the membrane.
The tanks are equipped with a special valve for filling or releasing air from the tank - the same valve as the one used in car tyres is located at the rear of the tank, under the cover.
IBO pressure vessels are pressure equipment compliant with requirements of Directive 2014/68/EU.
APPLICATION:
Connected with surface or deep-well pumps, they create booster sets for supplying water to allotments, single and multi-family houses, farms and
enterprises from their own intakes.
Specifications
Volume 24 liters
Inlet/outlet 1"
Operating temperature 0-60oC
Max. tested PT pressure 8 bar
Precharge pressure 1.7 +/-10% bar
Dimensions D 300 mm, H 450 mm
