Internet Thermostat iT500

Description

iT500 Internet controlled thermostat.

Access and control the heating system and A.C.M via the internet.
The PC and smartphone connect to the system using the internet.
The system is wireless / wireless - 868 Mhz
Components:
ITG500 (Gateway). This device connects via a UTP cable to the router. This device allows internet access and control of the system. Dimensions 90 mm (L) x 40 mm (L) x 25 mm (H).
IT500RX receiver. The wireless receiver will connect to your boiler. It can be installed at most thermal power plants sold in Romania. Dimensions 150 mm (L) x 100 mm (L) x 35 mm (H).
IT500 thermostat. Depending on the configuration of the system, you can use the thermostat to control the temperature in 1 or 2 zones * of the house, or to control one zone and A.C.M. Dimensions 125 mm (W) x 90 mm (W) x 25 mm (H). (* iT300 sensor is required to control 2 zones - separate cost, extra!).
* The iT300 sensor is only needed if you want to control the temperature in 2 areas of the house. This feature gives you extra comfort in your home. You will also benefit from considerable energy savings.

Temperature measuring range: 0-35 ° C; Temperature control range: 5-35 ° C (step 0.5 ° C) Hysteresis = 1 ° C
Frost protection temperature: adjustable from 1 ° C to 9 ° C (0.5 ° C step)
Maximum relay amperage Zone 1: 16 A (resistive), 5 A (inductive) / Zone 2 or A.C.M .: 5 A (resistive), 3 A (inductive)
Power supply: iT500 -2x AA batteries; iT300 -2x AAA batteries; iT500RX: 230V AC 50 Hz
Storage temperature: -20 ° C ... 60 ° C
Degree of protection IP: IP30.
