Stainless steel DHW Tank EKHWS(P)180D3V3

Name: Stainless steel DHW Tank EKHWS(P)180D3V3
Brand: Daikin
SKU: EKHWS(P)180D3V3

RON 7,632^.10 (VAT Included) RON 8,295^.76

Delivery costs are not included

Financing through Online Credit smart by BT Direct

Calculate the rate

How can we help you?

Ask for details

Send us a message

Description

consists of tank, booster heater, thermistor + connection wire (12 m), 3-way valve + motor, jumper wire.

					EKHWS150D3V3	EKHWS180D3V3	EKHWS200D3V3	EKHWS250D3V3	EKHWS300D3V3
Lisälämmitin	Capacity			kW	3	3	3	3	3
Heat exchanger	Kuuma käyttövesi		Putkimateriaali		Stainless steel (EN 1.4521)	Stainless steel (EN 1.4521)	Stainless steel (EN 1.4521)	Stainless steel (EN 1.4521)	Stainless steel (EN 1.4521)
			Käyttöpaine	bar	10	10	10	10	10
			Sisäisen kierukan tilavuus	l	4.9	6.5	8.2	8.2	8.2
			Määrä		1	1	1	1	1
Dimensions	Unit		Diameter	mm	595	595	595	595	595
		Height	Tank	mm	1,000	1,164	1,264	1,535	1,745
Casing	Material				Epoxy coated steel, Epoxy-coated mild steel	Epoxy coated steel, Epoxy-coated mild steel	Epoxy coated steel, Epoxy-coated mild steel	Epoxy coated steel, Epoxy-coated mild steel	Epoxy coated steel, Epoxy-coated mild steel
	Colour				Neutral white	Neutral white	Neutral white	Neutral white	Neutral white
Tank	Energy efficiency class				B	B	B	B	B
	Veden enimmäislämpötila			°C	75	75	75	75	75
	Materiaali				Stainless steel (EN 1.4521)	Stainless steel (EN 1.4521)	Stainless steel (EN 1.4521)	Stainless steel (EN 1.4521)	Stainless steel (EN 1.4521)
	Vesitilavuus			l	145	174	192	242	292
Weight	Unit		Empty	kg	45	50	53	58	63
			Full	kg	190	224	245	300	355
Notes					(1) - Heatloss according to EN12897	(1) - Heatloss according to EN12897	(1) - Heatloss according to EN12897	(1) - Heatloss according to EN12897	(1) - Heatloss according to EN12897
