Swimming pool pump Swim 075

Description

Self-priming swimming pool pump IBO Swim 075 with pre-filter

Designed for maximum efficiency of filtration and circulation of water with chlorine content.

It can operate with sea water. The pump is made of plastic materials, with a catcher for leaves and larger impurities, including fibrous ones.

Available with Ø 50 mm or Ø 48.5 mm inlets/outlets.

Motor

• Asynchronous squirrel-cage with external ventilation
• Supply voltage 220-240 V/ 50 Hz.
• IP55 Ingress Protection
• Insulation Class F
• Single-phase motor with built-in capacitor and thermal protection
• Self-lubricating ball bearings
• Rotational speed 2850 rpm
• Designed for continuous operation
Operating conditions:
• Water temperature: 5-50°C
• Ambient temperature: max. 50°C
• Max. working pressure: 0.3 MPa

Materials:

• Pump housing: ABS
• Pre-filter: ABS
• Inlet/outlet: ABS/PVC
• Access plate: Polyethylene HD
• Impeller: Glass fibre reinforced LEXAN (resistant to abrasion by sand)
• Venturi tube: Glass fibre reinforced LEXAN (resistant to abrasion by sand)
• Mechanical seal: SiC/C
• Shaft: Stainless steel SUS 316
• Base: Polypropylene
