Wired Remote Control Madoka BRC1HHD

Description

Wired Remote Control Daikin Madoka BRC1HHD

• Pure circle shape offers a sleek and stylish design
• Intuitive interface with touch button control
• Measuring 85x85 mm, this compact controller fits standard electrical installation boxes.

Three colours to match any interior design

No matter your interior design, Madoka will match it. Silver gives an additional touch to stand out in any interior or application, while Black is an ideal match for darker, stylish interiors. White offers a sleek, modern look.

Award-winning design

Madoka earned an IF design award and Reddot Product Design Award for its innovative design. These awards represent two of the most prestigious and largest design competitions in the world.

Advanced settings and commissioning can be easily done via your smarthphone

• Connect with your smartphone via Bluetooth Low Energy communication
• Visual interface helps you schedule, set point restriction and offers other settings for advanced users / technical managers
• Easy and time-saving commissioning for installers.


Easily set advanced settings

Setting and finetuning your controller is simple and helps you attain higher energy savings and more comfort. The system can host up to three different temperature schedules, and enables you to restrict menu functions individually.  You can also set your outdoor unit to a quiet mode and track the energy consumption.

Easy and time saving commissioning

Installers can quickly set all the parameters of the system. The interface on your smartphone enables you to work much faster compared to making the settings on the controller itself.

Also error read-out is easier making servicing faster.

Field settings and schedules can be saved on your phone and upload to multiple controllers, saving time and cost!

Madoka for residential heating

• Madoka is compatible with the latest generation of the air-to-water heat pump Daikin Altherma 3
• Similar to Madoka, the third generation of Daikin Altherma is also equipped with a Daikin Eye, allowing you to know the status of your system in the blink of an eye.

Japanese for circle, Madoka embodies gentleness and peace. Madoka echoes
the distinct blue circle and simplicity of design, which is the very reason why its
sleek and elegant look has won such praise, including the Red Dot Product Design Award and iF Design Award.

Madoka guarantees comfort in the most intuitive way imaginable, featuring just three buttons and a large-figure display.

Casing Colour
W = White (RAL 9003 (glossy))
S = Silver (RAL 9006 (metallic))
K = Black (RAL 9005 (matt))
LED operation Colour Blue status indicator
Dimensions Unit Height x Width x Depth 85 x 85 x 25 mm
Weight Unit 0.110 kg
LCD Back light Colour White
Maximum number of connectable indoor units 1 group (up to 16 indoor units)
Wiring connections
For connection with indoor P1-P2 wired connection from indoor unit Size mm² 0.75 ~ 1.25
Ambient temperature Operation Min.~Max. -10 ~ 50 °C
Relative humidity < 95%
Storage Min.~Max. - 20 ~ 70 °C
Back-up for power failure Yes - clock stays synchronised for up to 48 hours.
Bluetooth® wireless technology Protocol Bluetooth® low energy 4.2 or higher
App for advanced settings Madoka Assistant
App operation system Apple iOS 8.0 or higher, Android 5.0 or higher
