Wireless non-programmable Thermostat RT310RF
Description
Wireless, electronic thermostat Salus RT310RF - non-programmable
The thermostat is used to wirelessly control heating devices equipped with an ON / OFF thermostat input.
It works by maintaining comfortable conditions in the room, in accordance with the constant temperature set by the user. Recommended for controlling e.g. gas and oil boilers.
In the set:
• Thermostat's transmitter (RT310TX)
• Thermostat's receiver (RXRT510)
• thermostat stand
Product advantages:
• set factory-paired and ready to work
• has a TPI control algorithm
• automatically repeats the signal
• has a frost protection mode (temperature range 5 - 17 degrees)
• correction of the displayed temperature ± 3ºC
• has a HOLIDAY mode and SLEEP mode (suspending the function, e.g. outside the heating season)
• has unique transmission codes
• operates at 868 MHz - a stable and noise-resistant signal
• Heat / Cool mode selection (* Function available from software version v2.1)
Technical specifications
| Transmitter's power supply | 2 x AA batteries |
| Receiver's power supply | 230V AC 50 Hz |
| Rating max | 16(5) A |
| Output signal | NO/COM relay |
| Temperature range | 5 - 35°C |
| Display temperature accuracy | 0.1°C or 0.5°C |
| Control algorithm | TPI or Hysteresis ±0.25°C |
| Receiver's model | RXRT510 |
| Communication | Wireless, 868 Mhz |
| Transmitter's dimension [mm] | 96 x 96 x 27 |
| Receiver's dimension [mm] | 96 x 96 x 27 |
