Boiler with integrated DHW Tank Itaca KB 24

Name: Boiler with integrated DHW Tank Itaca KB 24
Brand: Fondital
SKU: KITR22KB24
Price: 10965.86 RON
Availability: InStock

RON 10,965^.86 (VAT Included) RON 11,249^.03

RON 9,062^.69 (VAT excluded)

Delivery costs are not included

Buy now, pay later from RON 217.25 / Month Details

How can we help you?

Call us: +40740015767 (Mo-Fr 9-18)

Ask for details

Send us a message

Description

Boiler with integrated DHW Tank Fondital Itaca KB 24

Wall-hung Condensing boiler with an integrated water tank for the production of DHW.

Compatible with SPOT smart thermostat

Ambient temperature probe supplied as standard
Modulation ratio 1:9
Thermally-insulated 45-litre stainless steel hot water storage tank
Time control of water heater heating
Management of one heating zone with ambient temperature probe and two zones with zone kit
Multifunction relay for connection to systems with zone valves or to solar plant or to remote alarm signal
Thermopolymer-covered stainless steel heat exchanger
Thermoregulation with external probe (optional)
Antilegionella function for water heater
Prearranged for connection to a recirculation system
Circolatore modulante ad alta efficienza con disareatore incorporato
Automatic by-pass

Technical Data

Nominal heat output (Pn) 23 kW
Seasonal energy efficiency of ambient heating (ηs) 92 %
Seasonal energy efficiency of ambient heating (ηs) (Boiler + ambient temperature probe) 95 %
Water heating energy efficiency (ηwh) 82 %
Nominal heat input (Qn) 23,7 kW
Nominal heat output (80-60°C) (Pn) 23,0 kW
Heat output (50-30°C) 25,0 kW
Reduced heat input (Qr) kW 3,0 kW
Useful efficiency at nominal input (80-60°C) 96,8 %
Useful efficiency at nominal input (50-30°C) 105,6 %
Useful efficiency at 30% (30°C return) 107,4 %
Heating expansion vessel capacity 10 l
DHW nominal heat input kW 27,3 kW
Specific DHW flow ∆T=30K 16,2 l/min.
NOx emission class - 6
Electric protection rating IP IPX4D

Dimensions 580x861x412 mm, Weight 74 kg.
