Circulating Pump OHI 32-80 180

Description

Circulating Pump IBO OHI 32-80 180

IBO OHI pumps are made of high quality materials and economical.

Manual speed-speed controllers ensure optimal adaptation to the system by means of practical characteristics.

Suitable for almost all heating and air-conditioning systems (+ 2°C to + 110°C).

Advantages of OHI series:

 • power saving and economy of boiler fuel
 • standart measurments
 • ease of installation and use
 • long failure-free performance
 • materials and parts are resistant agains aggressive water enviroment and do not require additional maintenance
 • pump design allows to separate control unit from the pump in case of failure or maintenance
 • quiet performance even in high speeds due to the materials used

 • suitable for drinking water

Technical parameters:

 • material: cast iron
 • bearing material: ceramics
 • input: 220-230 V / 50 Hz
 • spacing: 180 mm

 • power (1/2/3): 150 / 220 / 270 W
 • max flow(1/2/3): 43 l/min / 103 l/min / 160 l/min

 • max water level (1/2/3): 6,5 / 7,5 / 8 m
 • fluid temperature: 2-110°C
 • max pressure: 10 bar
 • protection: IP44
 • pipe union/diameter : 5/4" - DN 32
 • pump connection : 2" - DN 50
