Connected Home Receiver RCR110.2ZB

Name: Connected Home Receiver RCR110.2ZB
Brand: Siemens
SKU: S55772-T110
Price: 400.5 RON
Availability: InStock

RON 400^.50 (VAT Included) RON 601^.37

Delivery costs are not included

Buy now, pay later from RON 10.19 / Month Details

Financing through Online Credit smart by BT Direct

Calculate the rate

How can we help you?

Call us: +40751049108 (Mo-Fr 9-18)

Ask for details

Send us a message

Description

Connected Home Receiver Siemens RCR110.2ZB

For boiler, pump and DHW release
● Mains-powered receiver AC 230 V
● Communicates with Connected Home Hub via Zigbee network
● Output module in combination with Connected Home Thermostat wireless
RDZ101ZB
● Two voltage-free contacts for boiler/pump release or DHW switch
● LED indication of operating state
● Manual override of relay outputs
● Firmware upgrade over the air via Zigbee

Use: The RCR110.2ZB is part of Siemens Connected Home ecosystem.

Typical application:
● Residential apartments
● Single family homes

To control DHW and the following plant components:
● Gas, oil boilers or non-reversible heat pumps
● Zone valves
● Pumps
● Heat exchanger
● Continuous-flow water heater
● Small water heating systems

Functions

Network joining initiator
● Configurable function via mobile application "Connected Home" (downloadable from
Google Play™ or Apple App Store®) as:
– Zigbee network repeater
– Pump/boiler releaser
– Pump/boiler releaser and DHW switch
● Boiler or pump releaser based on heat demand from individual rooms/zones
● Output module in combination with Connected Home Thermostat wireless RDZ101ZB
● Independent DHW switch controllable via mobile application
● Manual override of relay outputs
● Support of factory reset
● Wireless communication

The RCR110.2ZB consists of two parts: Plastic housing which accommodates the electronics and Mounting plate.

Equipment combinations:

Connected Home Hub GTW100ZB S55772-T109 Connected Home Hub
Wireless actuator SSA911.02ZB S55181-A105 Radiator Valve act. Zigbee
Wireless thermostat RDZ101ZB S55772-T114 Connected Home Thermostat wireless

Specifications

Power supply
Operating voltage AC 230 V (+10/-15 %), Frequency 48…63 Hz
Power consumption including connected field devices 5 VA
Radio parameters
Frequency band 2.4…2.4835 GHz, Maximum radio-frequency power 15 dBm
Zigbee standard Zigbee 3.0
MAC protocol IEEE 802.15.4
Zigbee channels 11...26
Pairing method with GTW100ZB Global Link Key
Switching capacity of relays
Voltage AC 24…230 V
Current Q11- Q12 Maximum 5 A
Q11- Q14 Maximum 8 (2) A
Q21- Q22 Maximum 5 A
Q21- Q24 Maximum 8 (2) A
