FHM-C2 Mixing Shunt without FTC

Description

Danfoss FHM-C2 Mixing Shunt without FTC

The Danfoss compact mixing shunts are used for regulation of flow and supply temperature in hydronic floor heating systems.

The compact, flexible design allows mounting the mixing shunt directly to the manifold on both left and right side, with the primary pipe connection from the side or below.

A self-acting proportional regulator is used to regulate the supply temperature. The regulator ensures that the desired supply temperature to the underfloor heating system always remains constant.
A built-in check valve ensures correct flow direction. An air-vent on top and a thermometer completes the mixing shunt. An optional thermostat protects the floor against too high temperatures.
FHM-C1, FHM-C2 are equipped with a low-energy, variable speed pump (Grundfos UPM3 Auto).

The FHM-C1 and FHM-C2 compact mixing shunts can be mounted directly to the Danfoss manifold system without the use of special equipment.

By using Danfoss floor heating controls all expectations of a professional floor heating system are fullfilled.
Should water treatment be used it is essential that dosing instructions of the manufacturer are strictly observed. It is recommended that formulations
containing mineral oil are avoided.

Technical Data

Gross weight 3.83 kg, Net weight 0.1 kg
Description FHM-C2 Shunt without FTC
IP protection class IP 44
Product group FH- Mixing Shunts
Pump energy class A
pump type Grundfos UPM3 Auto 15-70
REACH Candidate List substances >0.1% Lead
SCIP dossier file name FHM-C2 Shunt without FTC
SCIP dossier no. 940d9489-05f7-455b-8959-a5fd5e15e6de
SCIP dossier product name FHM-C2 Shunt without FTC
Type Compact Mixing Shunts
