Regulator ECL Comfort 310

Description

ECL Comfort 310 is an electronic climate control temperature controller

for use in heating, district heating and cooling systems.

Energy savings can be achieved by properly controlling the flow temperature in the heating and cooling systems. Up to 4 circuits can be controlled.
The climate compensation function in the ECL Comfort controllers measures the outside temperature and properly controls the flow temperature in the heating system. The climate-compensated heating system increases comfort and saves energy.
The ECL Comfort 310 controller is configured for a variety of applications via an ECL programming key. The web interface ECL portal establishes communications with the ECL Comfort 310 in order to obtain a state-of-the-art Supervisory Control and Data Acquisition (SCADA) tool, efficient and easy to use by all users, service personnel and on time. commissioning. The service level may be increased and / or service costs may be reduced. The heating and / or cooling system is accessible virtually from anywhere and at any time via laptops or smartphones, which increases the level of services and reduces the response time to alarms. The ECL instrument software for the ECL Comfort 310 controller provides the possibility of remote control using the ECL Portal and OPC server software.
The ECL Comfort 310 controller is designed for comfort temperatures, optimum power consumption, easy installation via the ECL (Plug-and-Play) programming key and intuitive operation.
The improved energy saving is facilitated by climate compensation, temperature regulation according to time scheduling, optimization, as well as by limiting temperature, flow and return power.
The ECL Comfort 310 controller is easily operated using a selector (multifunction button) or remote control unit (RCU). The selector and the backlit display guide the user through the text menus corresponding to the selected language.
The ECL Comfort 310 controller is equipped with, among other things, an electronic output for controlling the motorized valve, a relay output for controlling the recirculation pump / switching valve, as well as an alarm output.
6 Pt 1000 temperature sensors can be connected. In addition, 4 inputs are configured when loading the application. The configuration can be: Pt 1000 temperature sensor input, analog input (0 - 10 V) or digital input. Depending on the application, the ECA 32 internal expansion module (inserted in the base unit of the controller) can provide additional input and output signals.
Destination: Universal equipment - 230 V a.c. The base unit is not included.
Supply voltage 230 Vac 50 Hz
Relay outputs: 6; Sensor inputs: 10
Min. Voltage power supply = 207 Vac; Max voltage power supply = 244 Vac
Electricity consumption = 5 VA; Relay load 4 (2) A - 230 V a.c. (4 A for ohmic load, 2 A for inductive load); Triac load 0.2 A / 230 V a.c.
Ambient temperature min. = 0 ° C; Ambient temperature max. = 55 ° C
Min. Temperature storage = -40 ° C Max. 70 ° C storage
72 hour programmer battery backup
Digital input: Possibility of charging at 12 V
Sensor type: Pt 1000, configurable input ohm / ° C; Protection class IP 41; Total length of the sensor cable 200 m
Dimensions = 220 x 110 x 78.7 mm.
