Rinsable Fine Filter FF06-11/4AA

Description

Rinsable fiine Filter resideo MinPlus FF06-1 1/4"

Threaded male connections, filter mesh size 100 micron.

Rinsable MiniPlus FF06 fine filters ensure a continous supply of filtered water. The fine filter prevents the ingress of foreign bodies, for example rust particles, strands of hemp and grains of sand and thus reduces the probability of corrosion.

Sediment collected at the bottom of the filter bowl can simply be removed by rinsing the filter.

Compact in size, these filters were designed to fit where space is limited.

Simple assembly
Filtered water supplied even during reverse rinsing
Shock resistant clear synthetic material filter bowl enables easy checking of filter contamination
Filter and complete filter bowl are replaceable
Body with female and male threads
All materials are ACS approved
All materials are KTW approved
Approved by TUEV LGA for low noise, Group 1 without limitations.

SPECIFICATIONS

DN Size 32 mm
Approvals and Standards DVGW
Controlled Media Drinking Water
Connection Type External Thread
Filter Mesh Size 100 micron
Flow Coefficient 9.5 Kvs
Filter Type Rinsable
Mounting Position horizontal
Operating Pressure (Max) 16 bar
Ambient Operating Temperature (Max) 40°C
Body Material Shock-resistant Transparent Synthetic
Port Diameter 1 in
