Floor Heating Room Thermostat FH-WT

Description

Floor Heating Room Thermostat Danfoss FH-WT

The electronic room thermostats FH-WT are used for single room temperature control, mainly in hydronic floor heating systems.

All thermostats are provided with easy max. and min. limitation of the setting range, as well as thermal feedback to improve accuracy.

LEDs behind the front cover indicates heat demand.

FH-WT is a standard room thermostat

Product details

Gross weight 0.09 kg, Net weight 0.09 kg
Actuator on radiator No
Adaptive learning No
Away input No
Capacitive touch No
Cooling input No
Description FH-WT Room Thermostat, Standard
Fits into switch frames No
Floor sensor enabled No
Frequency range [Hz] [Max] 60 Hz
Frequency range [Hz] [Min] 50 Hz
Heating control type Room Thermostat
In-wall No
Installation On-wall
Interfaces Wired 24V
IP protection class IP 20
NC/NO NC
Noiseless switching Yes
Number of actuators max 2
On-wall Yes
Product group Floor Heating Controls
Product name Room thermostat
PWM No
Scheduling No
Stem position Standard
Supply voltage [V] 24 V
Tamper proof No
Temperature control Yes
Temperature limitation No
Temperature set-back button No
Temperature setting range [°C] [Max] 30°C
Temperature setting range [°C] [Min] 6°C
Thermal feedback No
Type FH Room Thermostats
Valve excercise No
