Wireless Room thermostat EKRCTRDI3BA

Description

Wireless Room thermostat Daikin EKRCTRDI3BA

This accessory is part of the DHC ecosystem and communicates with a dedicated wireless connection.

All accessories of the system can be configured comfortably and individually via the ONECTA app.

The DHC Room Thermostat enables time-controlled regulation of your conventional radiators with DHC Radiator Thermostats, or of your floor heating in combination with DHC Floor Heating Controllers, and adjusts heating phases
to your individual needs.

The DHC Room Thermostat measures the room temperature and humidity and transmits these at intervals to the DHC Radiator Thermostats or DHC Floor Heating Controllers enabling room temperatures to be precisely controlled.

You can comfortably control the DHC Room Thermostat in combination with a DHC Access Point via the free app

Package contents

1 Daikin Home Controls Room Thermostat
1 Clip-on frame
1 Mounting plate
2 Double-sided adhesive strips
2 Screws 3.0 x 30 mm
2 Plugs 5 mm
2 1.5 V LR03/micro/AAA batteries
1 Installation and operation manual.

Technical specifications

Supply voltage: 2x 1.5 V LR03/micro/AAA
Current consumption: 50 mA max.
Battery life (typ.): 2 years
Degree of protection: IP20
Ambient temperature: 0 to 35 °C
Dimensions (W x H x D):
Without frame: 55 x 55 x 23.5 mm
Including frame: 86 x 86 x 25 mm
Weight: 100 g (including batteries)
Radio frequency:
F1: 868.3 MHz
F2: 869.525 MHz
Receiver category: SRD category 2
Typ. open area RF range: 250 m
Duty cycle:
F1: < 1 % per h
F2: < 10 % per h
Method of operation: Type 1
Degree of pollution: 2
