Description

Light Oil Burner Riello Gulliver RG1 32-60 kW

The Riello Gulliver RG one stage light oil burners series, is a complete range of products developed to respond to any request for home heating.

The Gulliver RG series is available in 10 different models, with an output ranging from 16,6 to 309,5 kW, divided in five different structures. All the models use the same components designed by Riello for the Gulliver series.

The high quality level guarantees safe working. In developing these burners, special attention was paid to reducing noise, to the easiness of installation and adjustment, to obtaining the smallest size possible to fit into any sort of boiler available on the market.

All the models are approved by the EN 267 European Standard and conform to European Directives for EMC, Low Voltage, Machinery and Boiler Efficiency.

All the Gulliver RG burners are fired before leaving the factory.

STATE OF SUPPLY

Specification

Completely automatic monobloc light oil burners, one stage operation, made up of:
- Fan with forward curve blades
- Cover lined with sound-proofing material
- Air damper, completely closed in stand by, with external adjustment, without need to remove the cover
- Single phase electric motor 230 V, 50 Hz
- Combustion head fitted with:
- stainless steel head cone, resistant to high temperatures
- ignition electrodes
- flame stability disk
- Geared pump for fuel supply, fitted with:
- filter
- pressure regulator
- attachments for fitting a pressure gauge and vacuum meter
- internal by-pass for preparing for single-pipe installations
- Fuel feed solenoid valve incorporated in the pump
- Photocell for flame detection
- Electronic flame control equipment
- Light oil nozzle
- IP X0D (IP 40) protection level
- PTC fuel pre-heater (optional)
- Reduced output ignition mechanism (optional).

Standard equipment:

- Two flexible pipes for connection to the light oil supply line
- Two nipples for connection to the pump
- Flange, screws and nuts for fixing
- Thermal screen
- 7-pin plug (not included in models with digital control box MO 550)
- Instruction handbook for installation, use and maintenance
- Spare parts catalogue.
