Magnetic filter Cleanex Mag HF1 3/4"

Description

Magnetic filter for thermal installation Cleanex Mag HF1 3/4" (22 mm)

The CLEANEX® MAG HF1 3/4 "(22MM) magnetic filter is the ideal solution to protect the heating systems equipped with steel or cast iron radiators against the harmful effects of magnetite and other impurities. The equipment can be easily installed in any position on the return of the heating installation, through the 360 ° adapter and the included 3/4 "isolation valves.
The standard package is ready to use for quick mounting on any type of pipe (copper, PPR, etc.), using adapters specific to the material from which it is made.

CLEANEX® MAG HF1 3/4 "(22MM) has a very important role in protecting the boiler and maintaining the proper functioning of the thermal circuit, allowing to keep the operation and maintenance cost of the system as low as possible.

✓ Retains magnetite and non-magnetic particles;
✓ Ensures the efficient operation of the heating system;
✓ Protects the central heating system from possible blockages due to deposits;
✓ The special design of the 360 ° adapter allows any mounting position;
✓ 3/4" brass ball valves included for easy operation
✓ Equipped with aerator and draining valve that allows a quick cleaning;
✓ Glass opener and spare gaskets included in the package;
✓ Compatible with thermotechnical antifreeze and other chemical solutions for protecting installation;

Being a premium equipment made of the highest quality materials, the CLEANEX® MAG HF1 3/4 "(22MM) anti-magnetite filter benefits from an extended 5 years warranty.

Technical specifications:

Magnet: 12000 Gauss
Maximum pressure: 4 bar
Temperature: 0-120 ° C
Volume of glass holding impurities: 240ml
To increase the efficiency in cleaning and protecting the installation, we also recommend the use of specific solutions from the CHEMSTAL range: Cleanex® Allround and Doctor Cleanex®.
